System.CommandLine

System.CommandLine provides robust support for command-line parsing, invocation, and shell completions in .NET applications. It supports both POSIX and Windows conventions, making it easy to build professional command-line interfaces.

Getting Started

Basic Command

Here's a simple "Hello World" command-line application:

using System.CommandLine;

RootCommand rootCommand = new("Sample command-line app");

Option<string> nameOption = new("--name", "-n")
{
    Description = "Your name"
};

rootCommand.Options.Add(nameOption);

rootCommand.SetAction(parseResult =>
{
    string name = parseResult.GetValue(nameOption);
    Console.WriteLine($"Hello, {name ?? "World"}!");
});

return rootCommand.Parse(args).Invoke();

In this example, we create a RootCommand, add an option for the user's name, and define an action that prints a greeting. The RootCommand is a special kind of Command that comes with a few predefined behaviors:

• It discovers its name automatically from the currently-running application
• It automatically provides --help and --version options and default behaviors for them
• It provides a default integration with dotnet-suggest for dynamic shell completions

You can always override or customize these behaviors as needed on a RootCommand, or create your own top-level Command instead.

Commands with Arguments

Arguments are values passed directly to commands without option names:

var fileArgument = new Argument<FileInfo>("file")
{
    Description = "The file to process"
};

var processCommand = new Command("process", "Process a file");
processCommand.Arguments.Add(fileArgument);

processCommand.SetAction(parseResult =>
{
    FileInfo file = parseResult.GetValue(fileArgument);
    Console.WriteLine($"Processing {file.FullName}");
});

var rootCommand = new RootCommand();

rootCommand.Subcommands.Add(processCommand);

Options with Default Values

Options can have default values and validation:

var rootCommand = new RootCommand();

var delayOption = new Option<int>("--delay", "-d")
{
    Description = "Delay in milliseconds",
    DefaultValueFactory = _ => 1000
};

delayOption.Validators.Add(result =>
{
    if (result.GetValueOrDefault<int>() < 0)
    {
        result.AddError("Delay must be non-negative");
    }
});

rootCommand.Options.Add(delayOption);

Subcommands

Build complex CLI applications with nested commands:

var rootCommand = new RootCommand("My application");

var configCommand = new Command("config", "Configure the application");
var configSetCommand = new Command("set", "Set a configuration value");
var configGetCommand = new Command("get", "Get a configuration value");

var keyOption = new Option<string>("--key")
{
    Description = "Configuration key"
};
var valueOption = new Option<string>("--value")
{
    Description = "Configuration value"
};

configSetCommand.Options.Add(keyOption);
configSetCommand.Options.Add(valueOption);
configGetCommand.Options.Add(keyOption);

configCommand.Subcommands.Add(configSetCommand);
configCommand.Subcommands.Add(configGetCommand);
rootCommand.Subcommands.Add(configCommand);

// Usage: myapp config set --key "apiUrl" --value "https://api.example.com"
// Usage: myapp config get --key "apiUrl"

Using Options in Command Actions

Access option values through the ParseResult:

var connectionOption = new Option<string>("--connection")
{
    Description = "Database connection string"
};
var timeoutOption = new Option<int>("--timeout")
{
    Description = "Timeout in seconds",
    DefaultValueFactory = _ => 30
};
var verboseOption = new Option<bool>("--verbose")
{
    Description = "Enable verbose output"
};

rootCommand.Options.Add(connectionOption);
rootCommand.Options.Add(timeoutOption);
rootCommand.Options.Add(verboseOption);

rootCommand.SetAction(parseResult =>
{
    var connection = parseResult.GetValue(connectionOption);
    var timeout = parseResult.GetValue(timeoutOption);
    var verbose = parseResult.GetValue(verboseOption);

    Console.WriteLine($"Connection: {connection}");
    Console.WriteLine($"Timeout: {timeout}");
    Console.WriteLine($"Verbose: {verbose}");
});

Shell Completions

Enable tab completion for your CLI:

// Completions are automatically available for all commands, options, and arguments
var rootCommand = new RootCommand("My app with completions");

var fileOption = new Option<FileInfo>("--file")
{
    Description = "The file to process"
};

// Add custom completions using CompletionSources
fileOption.CompletionSources.Add(ctx =>
    // hard-coded list of files
    ["file1.txt", "file2.txt", "file3.txt" ]
);

// Or add simple string suggestions
fileOption.CompletionSources.Add("option1", "option2", "option3");

rootCommand.Options.Add(fileOption);

Users can then easily trigger your completions using dotnet-suggest:

> dotnet tool install -g dotnet-suggest
> dotnet suggest script bash > ~/.bashrc

> dotnet tool install -g dotnet-suggest
> dotnet suggest script powershell >> $PROFILE

Once dotnet-suggest is installed, you can register your app with it for completions support:

> dotnet-suggest register --command-path /path/to/myapp

Alternatively, you can create your own commands for completion generation and instruct users on how to set them up.

Async Command Handlers

Support for asynchronous operations:

var urlOption = new Option<string>("--url")
{
    Description = "The URL to fetch"
};
rootCommand.Options.Add(urlOption);

rootCommand.SetAction(async (parseResult, cancellationToken) =>
{
    var url = parseResult.GetValue(urlOption);
    if (url != null)
    {
        using var client = new HttpClient();
        var response = await client.GetStringAsync(url, cancellationToken);
        Console.WriteLine(response);
    }
});

// Or return an exit code:
rootCommand.SetAction(async (parseResult, cancellationToken) =>
{
    // Your async logic here
    return await Task.FromResult(0); // Return exit code
});

Notable Changes Since v2.0.0-beta7

New Features

• Improved Help System: Enhanced HelpAction to allow users to provide custom MaxWidth for help text formatting (#2635). Note that if you create custom Help or Version actions, you'll want to set ClearsParseErrors to true to ensure that invoking those features isn't treated like an error by the parser.
• Task<int> Support: Added SetAction overload for Task<int> return types (#2634)
• Detect Implicit Arguments: Added the ArgumentResult.Implicit property for better argument handling (#2622, #2625)
• Performance Improvements: Reduced reflection usage throughout the library for better performance (#2662)

Bug Fixes

• Fixed issue #2128: Resolved command parsing edge cases (#2656)
• Fixed issue #2257: Corrected argument validation behavior
• Fixed issue #2589: Improved error message clarity (#2654)
• Fixed issue #2591: Resolved option parsing inconsistencies (#2644)
• Fixed issue #2622: Enhanced implicit argument support (#2625)
• Fixed issue #2628: Corrected help text formatting issues
• Fixed issue #2634: Added missing Task action support
• Fixed issue #2640: Resolved completion suggestions for nested commands (#2646)

Breaking Changes

• Default value handling for ProcessTerminationTimeout has been re-added (#2672)
• Some internal APIs have been refactored to reduce reflection usage (#2662)

Other Improvements

• Updated to .NET 10.0 RC1 compatibility
• Improved memory usage and performance optimizations
• Better handling of complex command hierarchies

Documentation

For comprehensive documentation, tutorials, and API reference, visit:

• Microsoft Learn Documentation - Complete guides and API reference
• GitHub Repository - Source code, samples, and issues

Framework Support

• .NET 8.0+ - Full feature support with trimming and AOT compilation
• .NET Standard 2.0 - Compatible with .NET Framework 4.6.1+, .NET Core 2.0+

License

This package is licensed under the MIT License.

Contributing

We welcome contributions! Please see our Contributing Guide for details.

Support

• Issues: GitHub Issues
• Discussions: GitHub Discussions
