ReactiveUI.Binding.SourceGenerators

You have a property. When it changes, something else needs to know: a label, a validation rule, another property. This library lets you say that in one line, and writes the wiring for you while you compile.

Table of Contents

• The problem it solves
• Your first binding
• How a property reports a change
• A chain is decided one link at a time
• What the generator writes
• How a call site reaches its generated code
• When nothing claims the call
• Installing
• Supported frameworks
• Packages
• Supported APIs
• Examples
• The view locator
• Which mechanism wins
• Which thread a binding writes on
• Rx library compatibility
• Performance
• Diagnostics
• Where this differs from ReactiveUI
• Layout
• Core team
• Contribute

Core Team

Chris Pulman London, UK

Glenn Watson Melbourne, Australia

The problem it solves

C# already tells you when a property changes. A class raises PropertyChanged, you attach a handler, you check which property the handler was told about, and you read the new value.

That is fine for one property. It goes badly as soon as you want a path through two of them:

// Tell me when the city changes.
viewModel.PropertyChanged += (sender, args) =>
{
    if (args.PropertyName != nameof(viewModel.Address))
    {
        return;
    }

    // Address was replaced. Detach from the old Address, attach to the new one,
    // and start watching its City. Then undo all of it when you are finished.
};

You write the path instead:

IObservable<string> city = viewModel.WhenChanged(x => x.Address.City);

That attaches to Address and to City, re-attaches further down when Address is replaced, and detaches everything when you dispose the subscription.

The lambda is there to name the path. The generator reads the properties out of it, Address and then City, and emits the code that fetches each one and attaches to whichever event reports it changing.

Your first binding

1. Install the package.

dotnet add package ReactiveUI.Binding

2. Raise PropertyChanged from your view model. Any class that does this can be observed. There is no base class to inherit.

public class PersonViewModel : INotifyPropertyChanged
{
    private string _name = "";

    public event PropertyChangedEventHandler? PropertyChanged;

    public string Name
    {
        get => _name;
        set
        {
            _name = value;
            PropertyChanged?.Invoke(this, new PropertyChangedEventArgs(nameof(Name)));
        }
    }
}

3. Observe a property. You get an IObservable<T>, which hands you the current value and then every later one.

var vm = new PersonViewModel { Name = "Ada" };

IDisposable subscription = vm.WhenChanged(x => x.Name)
    .Subscribe(name => Console.WriteLine(name));   // prints Ada

vm.Name = "Grace";                                // prints Grace

4. Or bind it straight to a control. This writes Name into the label and keeps writing it.

IDisposable binding = vm.BindOneWay(view, x => x.Name, v => v.NameLabel.Text);

5. Dispose when you are done. Both calls return an IDisposable. Disposing detaches every handler the binding attached.

That is the whole surface you need to start. WhenChanging, BindTwoWay, BindCommand and the rest follow the same shape.

How a property reports a change

PropertyChanged is one way for a property to report a change. It is not the only one. A WPF control does not raise it for TextBox.Text, and an iOS view does not raise it at all.

So the first thing the generator works out is which mechanism the declaring type offers. Each one is a different event, attached a different way.

Before-change observation needs the type to raise something before the value is replaced. Where it cannot, WhenChanging reads the value once and then stays silent, and RXUIBIND004 tells you so while you build. A WPF dependency property is the odd one out: it keeps a live subscription and delivers each new value.

A chain is decided one link at a time

x => x.Address.City is two properties, and they need not use the same mechanism. Address might be a plain property on a view model that raises PropertyChanged, while City sits on a WPF control.

The generator resolves each link separately, while you compile, and writes the right attach for each.

// Address: INotifyPropertyChanged on the view model.
// City:    a dependency property on the control it holds.
vm.WhenChanged(x => x.Address.City);

When Address is replaced, the subscription below it is torn down and rebuilt against the new object. That is the part you would otherwise hand-write, and the part most easily got wrong.

What the generator writes

Here is what it emits for vm.WhenChanged(x => x.Name) on a class that raises PropertyChanged:

private static global::System.IObservable<string> __WhenChanged_7FFFD2E8D6FC818E(MyViewModel obj)
{
    return global::ReactiveUI.Binding.Observables.PluginObservationSource.Choose<string>(
        obj,
        ((Expression<Func<MyViewModel, string>>)(__e => __e.Name)).Body,
        "Name",
        false,
        5,
        (object __o) => ((MyViewModel)__o).Name,
        new global::ReactiveUI.Binding.Observables.PropertyObservable<string>(
            obj, "Name", (INotifyPropertyChanged __o) => ((MyViewModel)__o).Name, true));
}

The last argument is the subscription it chose. Everything that subscription needs is fixed at compile time: the declaring type, the property name, and a getter that is a direct call rather than a lookup.

Choose offers the link to any ICreatesObservableForProperty you registered yourself, and takes yours when it scores higher than the mechanism the generator picked. That is how a platform plugin still wins, without costing any reflection.

ReactiveUI does this same job at run time instead. It compiles the lambda into a delegate and then finds each property by name. That costs time on every binding, and a trimmer cannot see which members the reflection will ask for, so it may remove them.

How a call site reaches its generated code

Your compiler decides this, and it matters only when something goes wrong.

Roslyn 4.13 and newer intercept the call, which means the compiler runs the generated method in place of yours. Nothing goes through name lookup, so it works from any file and any language version, including <LangVersion>7.3</LangVersion> on .NET Framework 4.6.2.

Roslyn 4.8 to 4.12 emit an overload that competes for the call instead. It wins wherever extension-method lookup finds it, and RXUIBIND009 tells you where it will not.

Both routes run the same method, so a binding behaves the same either way.

Set ReactiveUIBindingUseInterceptors to false to take the overloads on a compiler that could intercept. Set ReactiveUIBindingEmitGeneratedCodeMarkers to false to drop the // <auto-generated/> header from emitted files, which lets analyzer and compiler diagnostics inside them surface.

The generator and analyzer are packed once per compiler generation:

analyzers/dotnet/roslyn4.8/cs/    <- Roslyn 4.8 to 4.12
analyzers/dotnet/roslyn4.13/cs/   <- Roslyn 4.13 and newer

The .NET SDK picks the highest folder your compiler supports. A legacy non-SDK project is handed both, so the package's targets remove the one you are not being served by. Loading the generator twice would emit every dispatch file twice and fail your build.

When nothing claims the call

Some call sites cannot be read while you compile. An expression held in a variable, one assembled at run time, or a receiver typed as a type parameter all name no path the generator can see.

Those call sites get the Unsafe overload, which is ReactiveUI's reflection pipeline. It walks the chain at run time and finds each property by name, so it is not guaranteed to survive trimming or ahead-of-time publishing. Every other overload is.

Asking for the plain name where nothing was generated throws, and the message names the overload that resolves it:

Expression<Func<MyViewModel, string>> selector = x => x.Name;

vm.WhenChanged(selector);        // throws, and names WhenChangedUnsafe
vm.WhenChangedUnsafe(selector);  // walks the chain by reflection

Thirteen APIs have an Unsafe twin.

Every Unsafe overload carries [RequiresUnreferencedCode]. The overloads a generated dispatch displaces carry none. A PublishTrimmed or PublishAot build therefore reports the call sites that asked for reflection and says nothing about the rest. RXUIBIND001, RXUIBIND006 and RXUIBIND009 name those call sites while you build, before anything throws.

The scheduler overloads split the same way, and both halves live on ReactiveSchedulerExtensions.

Two members have no compile-time half, so their unsuffixed names carry the annotation themselves.

• WhenAnyDynamic takes the chain as an Expression you built. There is no lambda to read.
• ViewLocator's object-typed ResolveView closes IViewFor<> over a runtime type, so it carries [RequiresDynamicCode]. The generic overload does not.

Installing

dotnet add package ReactiveUI.Binding

The generator and the analyzer ship inside that package. There is nothing else to reference.

Install ReactiveUI.Binding.Reactive instead if your application speaks System.Reactive. It is the same library compiled against System.Reactive.Concurrency.IScheduler, under the ReactiveUI.Binding.Reactive.* namespaces. Reference one or the other, not both.

Supported frameworks

The WPF and WinForms packages target the .NET Framework versions and the Windows heads of .NET 8 to 11. The MAUI packages start at .NET 10 and add Android, iOS, macOS, Mac Catalyst and tvOS heads; the Apple heads build only on Windows and macOS.

NativeAOT works on .NET 8 and later. The generated path is the only one that runs there at all, because the reflection engine compiles expressions at run time.

Packages

Ten packages ship. Each runtime package carries the generator and the analyzer; the platform packages inherit them.

Supported APIs

Every one of them reads a single property, a deep chain such as x => x.Address.City, or several properties at once. A deep chain re-subscribes when an intermediate object is replaced.

BindOneWay, BindTwoWay, OneWayBind and Bind also take a scheduler. No observation API does.

Examples

Observing a property

// One property.
IObservable<string> name = vm.WhenChanged(x => x.Name);

// A chain. Replacing Address re-subscribes.
IObservable<string> city = vm.WhenChanged(x => x.Address.City);

// Several properties, combined by a selector.
IObservable<string> fullName = vm.WhenChanged(
    x => x.FirstName,
    x => x.LastName,
    (first, last) => $"{first} {last}");

// Before the change. The type has to raise PropertyChanging.
IObservable<string> before = vm.WhenChanging(x => x.Name);

Binding

// One way.
IDisposable binding = vm.BindOneWay(view, x => x.Name, x => x.NameLabel);

// One way, converting on the way through.
IDisposable converted = vm.BindOneWay(view, x => x.Age, x => x.AgeLabel, age => $"Age: {age}");

// Both ways.
IDisposable twoWay = vm.BindTwoWay(view, x => x.Name, x => x.NameTextBox);

// Both ways, with a converter per direction.
IDisposable pair = vm.BindTwoWay(
    view,
    x => x.Age,
    x => x.AgeTextBox,
    age => age.ToString(),
    text => int.TryParse(text, out var n) ? n : 0);

// On a scheduler.
IDisposable scheduled = vm.BindOneWay(
    view, x => x.Name, x => x.NameLabel, scheduler: RxApp.MainThreadScheduler);

OneWayBind and Bind are the same bindings written view first, for code moving across from ReactiveUI:

IDisposable oneWay = view.OneWayBind(vm, x => x.Name, x => x.NameLabel);
IDisposable twoWay = view.Bind(vm, x => x.Name, x => x.NameTextBox);

Running a command

// The command lives on a view model property. Each value becomes the command parameter,
// and a value CanExecute refuses is dropped.
IDisposable invocation = searchText.InvokeCommand(vm, x => x.Search);

// The caller holds the command, so there is no property to observe.
IDisposable direct = searchText.InvokeCommand(vm.Search);

A ReactiveCommand is reached like any other ICommand. The parameter arrives as object rather than the command's declared input type.

Observing a chain built at run time

WhenAnyDynamic takes the chain as an Expression rather than a lambda, so it can be assembled from a property name or a configuration entry. Arities 1 to 12 are available, each with and without a distinct gate.

Expression chain = ((Expression<Func<MyViewModel, string>>)(x => x.Address.City)).Body;

IObservable<string?> city = vm.WhenAnyDynamic(chain, static c => (string?)c.Value);

There is nothing for a generator to read in an expression built at run time, so the chain is walked by reflection. Every overload carries [RequiresUnreferencedCode] and each call site is reported in a PublishAot build. Where the chain is known while you compile, WhenChanged and WhenAny observe the same thing with no reflection at all.

The view locator

Implement IViewFor<T> and the generator registers the mapping for you.

public class LoginView : IViewFor<LoginViewModel>
{
    public LoginViewModel ViewModel { get; set; }

    object IViewFor.ViewModel
    {
        get => ViewModel;
        set => ViewModel = (LoginViewModel)value;
    }
}

IViewFor? view = ViewLocator.GetCurrent().ResolveView(myViewModel);

Three attributes change what is registered.

[ViewContract("compact")]
public class CompactDashboardView : IViewFor<DashboardViewModel> { }

public class FullDashboardView : IViewFor<DashboardViewModel> { }

var compact = ViewLocator.GetCurrent().ResolveView(vm, "compact");
var full = ViewLocator.GetCurrent().ResolveView(vm);

A resolution is tried in three places, in order.

1. The generated dispatch, which is a type switch with no reflection in it.
2. A mapping you added at run time with Map<TViewModel, TView>().
3. The service locator, Splat.AppLocator.Current.

Inside the generated dispatch, a contract is matched before the default view. The view then comes from the service locator, and failing that from a constructor call, or from a cache when the view is marked [SingleInstanceView]. The cache is filled with Interlocked.CompareExchange, so two threads resolving at once share one instance.

Resolve through the generic overload where you can. The object-typed overload closes IViewFor<> over a runtime type, so it carries [RequiresDynamicCode] and is not safe to publish ahead of time.

Which mechanism wins

A type can offer several mechanisms, so each one carries a score. The highest score that can actually reach the property you named wins.

"Can reach" is the important half. A dependency object's plain CLR property is not a dependency property, and a component with no {PropertyName}Changed event has nothing to attach to, so both fall through to the next mechanism down. INotifyPropertyChanged and Android.Views.View share a score, and that tie goes to INotifyPropertyChanged.

An ICreatesObservableForProperty you register yourself is scored against the same scale, and takes the link when it scores higher. A tie goes to the generated code.

Which thread a binding writes on

A view model raises its change notification on whichever thread did the work. A UI framework lets you touch a view only from the thread that owns it. A binding therefore moves the write for you, so an update from a background task lands where the view can take it.

Which thread that is belongs to the object being written, not to the process, so the platform package asks the object.

That distinction matters as soon as an application has more than one UI thread. WPF allows several, each owning its own windows, and a write sent to the wrong one throws exactly as an unmarshalled write does.

A write that is already on the owning thread is applied inline, so setting a property on the UI thread and reading the control back on the next line behaves as it reads. Only a write from another thread waits for a turn of the message loop.

An application can name one thread for everything else with BindingSchedulers.UseSynchronizationContext(context). It is consulted only for targets no platform package claims. Where neither answers - a console host, a test, a platform with no thread affinity - writes are delivered inline and cost nothing.

Rx library compatibility

The observables and operators come from ReactiveUI.Primitives. That is the library this one is built on, and it is the only Rx dependency the lean package has.

System.Reactive is reached through Primitives' own shim, ReactiveUI.Primitives.Reactive. Neither package here references System.Reactive directly.

Everything a binding hands back is an IObservable<T> from the BCL, so a consumer is not tied to either.

Performance

Removing the expression tree and the name lookups makes a binding several times faster and allocates several times less than the reflection engine, and it is the only path that runs under NativeAOT at all.

On .NET 10, a thousand property changes through a two-way binding cost 53.6 us and 42.2 KB where ReactiveUI's engine costs 686.5 us and 932.3 KB. Observing one property costs 79.5 us and 65.5 KB against 145.6 us and 105.5 KB. Published ahead of time the same code measures within a few per cent of the JIT, which the expression engine cannot do at all.

The suite behind those figures, the machine they were measured on, what each benchmark covers and how to run it are all in src/benchmarks/README.md.

Diagnostics

The analyzer ships inside the runtime packages and reports these.

The package's targets report one error of their own.

Where this differs from ReactiveUI

Each difference below is deliberate. Generating the equivalent would put reflection back on the path that exists to remove it. Nothing else in the binding surface behaves differently.

TriggerUpdate and signalViewUpdate are not offered

ReactiveUI's Bind accepts both. The first chooses which side wins the first write. The second replaces the view's change stream with one you supply.

Neither has a generated overload, so asking for one does not compile. A generated binding is resolved from the two lambdas alone, and an overload taking a caller-supplied stream has nothing to resolve while you compile. It would have to hand the call to the runtime engine, which carries [RequiresUnreferencedCode] and breaks a PublishAot build for everyone who calls it.

The first write follows ReactiveUI's default. The view model side is applied first. The view's own first value is then weighed against what was just written, and dropped when the two are equal.

A binding made through a type parameter is not generated

A generated overload has to name the bound types. A call made through a type parameter names none, because the type is only known once something closes it. Those call sites are left to the stub, so a generic binding helper compiles and throws when it runs. Emitting an overload that named a type parameter would fail your build outright. Call the Unsafe twin from the helper to bind it by reflection, which also marks the helper as the reflection boundary it is.

A silent link is reported while you build

ReactiveUI logs a warning the first time it observes a property on a type that raises no notification. RXUIBIND010 reports the same thing while you compile, which is the only place a generator can say it. The observation behaves the same either way: the value is read once, and the path is followed no further.

A write that faults behaves identically

A write that throws is logged against the bound expression, and rethrown as a TargetInvocationException only when it carries an inner exception. This is parity, not divergence, and it is not optional. A setter that throws on the notifying thread has no caller stack to surface on, so swallowing it would lose the failure entirely.

Layout

src/
  ReactiveUI.Binding/                     Runtime package, lightweight observables
  ReactiveUI.Binding.Reactive/            Runtime package, System.Reactive schedulers
  ReactiveUI.Binding.Shared/              The runtime source, compiled by both packages above
  ReactiveUI.Binding.SourceGenerators/    The generator, and the shipped props and targets
  ReactiveUI.Binding.Analyzer/            The RXUIBIND analyzers
  ReactiveUI.Binding.*.Roslyn413/         The same generator and analyzer against Roslyn 4.13
  ReactiveUI.Binding.Wpf*/                WPF integration, one package per runtime flavour
  ReactiveUI.Binding.WinForms*/           WinForms integration, one package per runtime flavour
  ReactiveUI.Binding.Maui*/               MAUI integration, one package per runtime flavour
  benchmarks/                             BenchmarkDotNet projects
  tests/                                  Test projects and the shared scenario sources

A *.Shared folder is source rather than a project. Each leaf compiles its own copy, which is how one body of code serves both runtime flavours: ReactiveShim.props keys on the .Reactive suffix, defines REACTIVE_SHIM, and aliases the scheduler type.

The generator and the analyzer target netstandard2.0, because Roslyn requires it. Generated output is C# 7.3 compatible, so the oldest supported consumer can compile it.

Contribute

ReactiveUI.Binding.SourceGenerators is developed under an OSI-approved open source license, making it freely usable and distributable, even for commercial use. We value the people who are involved in this project, and we'd love to have you on board, especially if you are just getting started or have never contributed to open-source before.

So here's to you, lovely person who wants to join us -- this is how you can support us:

• Responding to questions on GitHub Discussions
• Passing on knowledge and teaching the next generation of developers
• Submitting documentation updates where you see fit or lacking.
• Making contributions to the code base.
